5VDC 24VDC 120W Dual Output AC DC Regulated Switching Power Supply Unit

HS-120-12D series single output switching power supplyFeatures:·universal AC input voltage·Small volume,low weight,high efficiency·Protections:short circuit/over load·cooling by free air convection·LED indicator for power on·100% full load burn-in test·2 Years warrantyModel Specif

Featured Products



HS-120-12D series single output switching power supply
Features:
·universal AC input voltage
·Small volume,low weight,high efficiency
·Protections:short circuit/over load
·cooling by free air convection
·LED indicator for power on
·100% full load burn-in test
·2 Years warranty
Model SpecificationHS-120-12DHS-120-24D
DC output voltage C H 1: 5 VCH2:12VC H 1: 5 VC H 2:24 V
Output voltage error(Note:2)±2%5%~-8%±3%+6%~-8%
Rated output current12A5A6A4A
Output current rage 2-12A0.5-5A 1-6A0.4~4A
Wave and noise(Note :3)80mVp-p120mVp-p80mVp-p150mVp-p
DC output power 120W126W
Efficiency78%80%
Adjustable range for DC voltage CH1:-9%~+10%
AC input voltage range 90~132VAC, 180~264VAC(select by switch) 47~63Hz,255~373VDC
Input current2.8A/115V 1.6A/230VAC
AC Inrush current Cold-start current 50A/230V
Leakage current <3.5mA/240VAC
Overload protection CH1:115%~135% Type:Foldback:current limiting reset: auto recovery
Temperature coefficient±0.03%/ºC(0-50ºC)
Setup rise hold up time 200ms,50ms,20ms
Vibration10-500Hz,2G 10min,/1cycle,Period for60min,Each axes
Withstand voltage Input and output internal:1.5KVAC,Input and enclosure:1.5KVAC,Output and enclosure:0.5KVAC
Isolation resistanceInput and output internal: Input and enclosure, Output and enclosure:500VDC/100MΩ
Working temperature and humidity -10ºC~+60ºC(Refer to output derating curve),20%~90%RH
Store temperature and humidity -20ºC~+85ºC.10%~95%RH
Overall dimension199*110*50mm(L*W*H)
Weight0.85Kgs
Note:
1.The testing condition for the parameter above is :230VAC input, rated load,25ºC70% RH.Humidity.
2. Error.include the setting error, line stability and load stability. (Note: 5).
3.Wave test: adopting "A12"double wire for 20MHz, and 0.1UF&47UF capacitor short-circuit for interrupting.
4. Inlet voltage stability test: when is over load, the lowest voltage of inlet is up to the highest voltage.
5. Load stability test: the load is from 0% to 100%.
