500W switching power supply monitoring stabilized lamp with power supply AC 220V to DC 60V 8A

Origin: Wenzhou, ChinaBrand Name: AAVNModel: S- 500 - 60VOutput power: 500 WOutput type: single groupInput voltage: 110 v / 220 v, 85-264 vacOutput voltage: 60VOutput frequency: 47-63 HzOutput current: 8ASize: 215*115*50mmWeight: 1KGQuality assurance: 1 yearProtection: short circuit, overload, over voltage, over temperatureEffic

Featured Products

Origin: Wenzhou, China
Brand Name: AAVN
Model: S- 500 - 60V
Output power: 500 W
Output type: single group
Input voltage: 110 v / 220 v, 85-264 vac
Output voltage: 60V
Output frequency: 47-63 Hz
Output current: 8A
Size: 215*115*50mm
Weight: 1KG
Quality assurance: 1 year
Protection: short circuit, overload, over voltage, over temperature
Efficiency: >85%
Working temperature: -10 ~ 60ºC
Safety certificate: CE ROSH CCC


500W Switching power supply
DC output voltage12V24V36V48V60V80V110V
Output voltage tolerance±1%±1%±1%±1%±1%±1%±1%
Rated output current42A20A13A10A8A6A4A
Output current range0-42A0-20A0-13A0-10A0-8A0-6A0-4A
Output current range120
mVp-p
120 mVp-p120 mVp-p120 mVp-p120 mVp-p120 mVp-p120 mVp-p
Incoming line stability±1%±1%±1%±1%±1%±1%±1%
Load stability±1%±1%±1%±1%±1%±1%±1%
DC output power500W500W500W500W500W500W500W
Efficiency85%85%85%85%85%85%85%
DC voltage adjustable range0-12V0-24V0-36V0-48V0-60V0-80V0-110V
Input voltage range190-240VAC/47~63HZ
Input current5A/230V
Impulse current46A/230V
Leakage current<3.5MA/240VAC
Overload protection120%~150%, type: cut off the output, reset: automatic recovery
Overvoltage protection120%-150%
High temperature protectionERH365ºC 70ºC fan start, 55ºC~60ºC fan close, 80ºC~85ºC, cut off output (5~15V)~(24~48V)
Temperature coefficient±0.03%/ºC(0-50ºC)
Start, rise, hold time1S,100MS,50MS
Vibration resistance10~500HZ, 2G 10min,/1 cycle, duration 60 minutes, each axis
Pressure resistance Between input and output: 1.5KVAC Input and shell: 1.5KVAC Output and shell: 0.5KVAC
Isolation resistancebetween input and output; input and shell, output and shell; 500VDC/100MΩ
Working temperature and humidity-10ºC~+60ºC (refer to output characteristic diagram), 20%~90%RH
Storage temperature and humidity-20ºC~+85ºC,10%~95%RH
Dimensions215*115*50mm
Weight1KG
Safety standardsGB4949UL60950,EN60950
EMC standardAccording to GB9254 EN55022 EN55024 Class A design


AAVN focuses on providing LED switching power supplies, waterproof switching power supplies, rainproof switching power supplies and AC and DC power adapters. With overload protection, overvoltage protection and high temperature protection. AAVN has won the favor of customers for its high efficiency, reliability and long life. Each switching power supply is very safe and stable after 5 tests. All our forces have CE, ROHS ,CCC certification. Our switching power supplies are widely used in the field of industrial automation, indoor and outdoor LED lighting, and LED lighting projects.
